SWAT

SWAT 4.0 internal downtube storage

CUADRO

FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel

ABRAZADERA

Alloy, 38.6mm

SUSPENSION TRASERA

FOX FLOAT Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/ LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm

HORQUILLA

FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel

FRENO DELANTERO

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm

FRENO TRASERO

SRAM Maven Bronze, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm

PALANCA DE CAMBIOS

SRAM AXS POD Controller

DESVIADOR TRASERO

SRAM S1000 Eagle Transmission Derailleur

CASSETTE

SRAM XS-1270 Transmission Cassette, 12spd, 10-52t

CADENA

SRAM GX Eagle Transmission Flattop Chain

PEDALIER

SRAM S1000 Crankset, 32T ring, Integrated Guard, 55mm Chainline, S1-S3:165mm, S4-S6: 170mm

EJE DE CENTRO

SRAM DUB, BSA 73mm Wide, Threaded

LLANTAS

Specialized, hookless alloy, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2:27.5, S3- S6:29

MAZA DELANTERA

Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h

MAZA TRASERA

Alloy, sealed cartridge bearings, 12x148mm thru-axle, 28h

RAYOS

DT Swiss Industry

LLANTA DELANTERA

Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"

NEUMÁTICO TRASERO

Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"

CAMARAS

Standard, Presta valve

POSTE

Alloy Trail Stem, 35mm bar bore

MANUBRIO

Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S1-S2: 780 width, 20mm rise: S3-S4: 800 width, 30mm rise: S5-S6: 800 width, 40mm rise

PUÑOS

Specialized Trail Grips

ASIENTO

Bridge Comp, Hollow Cr-mo rails, S1-S2: 155mm, S3-S6: 143mm

POSTE DE ASIENTO

X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 190mm
